paper sheeter machine
"
Kağıt Tabakalama Makinesi Kağıt CHM Makine Tek Tabakalama
CHM-1100/14001700/1900 Precision High Speed Single Rotary Knife Paper Sheeter MachineConfiguration:Unwind Stand :automatic tension system and features multi-point automatic braking.Auto-EPC(Edge Paper Control)Deculler System( Anti-curvature Device)Middle Slitting and Waste Edge Collecting SystemHigh precision single rotary sheet cutterPaper Conveyer SystemElectrostatic eliminator SystemAuto-Squareness Adjustment SystemAuto counting and Label inserting deviceeAuto Jogger
Kağıt Kesme Makinesi Senkronize-Uçan Kesme Makinesi Çift Döner Kağıt Kesme Makinesi
CHM-SGT1400/1700H High Precision Synchronize-fly Sheeter Paper Sheeting Machinery Product Overview High Precision Synchronize-fly Sheeter features fiber-less clean cuts with high dimensional precision. Ideal for board paper, art paper, kraft paper, packing paper, and various board materials. High Precision Synchronize-fly Sheeter CHM-SGT1400H/1700H Double rotray sheeter machine , Refence weight of cutting paper :150-1000gsm. CHM-SGT1400H -Max. cutting width: 1500mm (59") CHM
Tek döner Kağıt Dilimleme Makinesi
±0,5 mm hassasiyet, 300 m/dak kesme hızı ve PLC servo kontrollü, yüksek hızlı tek döner kağıt tabakalama makinesi. Üstün verimlilik için otomatik gerginlik, kenar kontrolü ve atık toplama sistemleriyle 60-550 gsm kağıdı işler.
Kağıt yapıştırma makinesini, kağıt yapıştırma makinesini, kağıt yapıştırma makinesini, kağıt yapıştırma makinesini
CHM High Speed Precision Paper Sheeter 1400-1900mm 300m/min Product Specifications Cutting Way Top blade rotary, bottom blade fixed Reference weight of cutting paper 60-550GSM Cutting accuracy ±0.5mm Max cutting speed 300sheets/min Max.cutting meter speed 300m/min Cutting length range 450-1650mm Max scroll diameter 1800mm Stacking height Of paperboard 1500mm(59") Product Description Ac servo-driven system for exceptional speed, precision, and efficiency. The single rotary
AC Serisi Kağıt Yapraklama Makinesi CHM1400- 1900mm
Ac Series High Speed Precision Paper Sheeter Machine CHM-1400/1700/1900mm Product Specifications Cutting Way Top blade rotary, bottom blade fixed Reference weight of cutting paper 60-550GSM Cutting accuracy ±0.5mm Max cutting speed 300sheets/min Max.cutting meter speed 300m/min Cutting length range 450-1650mm Max scroll diameter 1800mm Stacking height Of paperboard 1500mm(59") Product Overview The CHM Series High Speed Precision Paper Sheeter features a servo-driven cutting
CHM Makinesi Tam Otomatik A4 Kağıt Kesme ve Paketleme Makinesi Üretim Hattı, Maksimum 280m/dak Hız
CHM-A4 Fully Automatic Paper Sheeting and Packaging Production Line The CHM-A4 high-speed production line delivers exceptional output of 20-35 reams per minute, capable of processing 20-30 tonnes in 8 hours. This fully automated system integrates electrical automation, PLC control, and mechanical automation for continuous production from ream collection to final discharge. Key Specifications Attribute Value Production Speed Max 280 m/min Cutting Accuracy ±0.2 mm Power
Yüksek Hızlı 300 kesim / dakikası AC Servo-Driven Precision Cutting ± 0.5mm Jumbo Kağıt Ruloları için Kağıt Yaprak Makinesi
CHM-1100 yüksek hızlı kağıt tabakalama makinesi, maksimum 1500 mm makara çapına sahip 60-500 GSM kağıdı işler. AC servo sürücüye, ±0,5 mm kesme doğruluğuna, 300 kesim/dakika hıza sahiptir ve aynı anda 2 ruloyu işler. Baskı, paketleme ve kağıt endüstrileri için idealdir.
CHM Ekonomik Çift Seri Yüksek Hızlı Kağıt Giydirme Makinesi
Technical Parameter Model CHM-SGT1400E 1. Type of cutting Top blade and bottom blade rotary 2. weight of paper 200-1000 GSM 3. reel diameter Max 1800mm(71") 4. Finished width Max 1400mm(55”) 5. Finished sheet-Length Min.450-Max.1650 mm 6. Num. of rolls cutting 2 rolls 7. Cutting accuracy ±0.5mm(L
Otomatik Çift Döner Kağıt Dilimleme Makinesi Ek Yapma & Palet Değişimi & Kesme Bıçağı Konumlandırması
CHM-SGT1400/1700/1900 Precision High Speed Double Rotary Paper Sheeting Machines CHM-SGT1400/1700/1900 Sync-Fly Sheeter: High Precision Synchronize - fly Sheeter features fibrelessand clean cuts with high dimensional precisions. Best for board paper,art paper, kraft paper and packing paper or board etc.automatic paper splicing system& pallet change system& pneumatic slitting knife system,improving production efficiency.High-precision fibreless cuts, fits various papers. Auto
